Frame/Shock:
SL Primer Carbon Front and Rear Triangle: 300 grams lighter with titanium hardware, high modulus carbon fiber and carbon top link.
I-Box Pivot System: With the suspension link nested directly above the bottom bracket, the bike is allowed a super short chainstay to give it a shorter, more nimble wheel base.
Adjustable Rear Travel: 130 mm - 115 mm
Fox Performance Elite Float SV EVOL: New design offers improved bump absorption and firm lockout. New DPS damper with three positions to match any terrain. Extra Volume (EVOL) air sleeve significantly reduces the force to initiate travel, providing added sensitivity and better small bump compliance.
Internal Cable Routing: For derailleur, brake, and dropper post routing.
Tapered Head Tube
Integrated Boost 148 x 12 Dropouts
Downtube Flak Guard Armor
H20 Bottle Fitment
Angular Contact / Collet Bearing System w/ Replaceable Grease Zerks
Fork:
Fox Performance Elite 34 Float: Designed for the aggressive trail rider, the 34 has been completely re-imagined from the inside out, featuring an all-new FIT4 damper, FLOAT air spring, and super lightweight chassis. It drops significant weight over its predecessor while providing improved trail performance that instills confidence and control.
3 Position Lever w/ Open Mode Adjust
Drive Train:
SRAM X01 Rear Derailleur: Large upper pully offset automatically adjusts chain gap. X-HORIZON™ design reduces shift force and ghost shifting. 12-tooth X-SYNC™ pulley wheels. Sealed cartridge bearings.
Race Face Next Crankset: The crank arms are completely hollow with all unnecessary material being removed from the center core - no internal aluminum spine. Industry standard 30mm spline interface CNC machined from a newly commercialized aluminum super alloy that is 20% stronger than 7050 alloy. Removable spider offers the ability to convert between existing chainring standards while remaining flexible to future developments.
SRAM XG-1175 10-42T Cassette: FULL PIN™ technology uses ten lightweight, stamped steel cogs and one 42t aluminum cog held together with 123 high-strength stainless steel pins. The result: a cassette that's light, durable and equipped with SRAM's super wide 10-42 gear range that's a perfect fit for any ride. The open design aids in mud clearance, giving you cleaner shifting performance and longer component life.
SRAM X1 11-Speed Shifter: 1x X-ACTUATION™ for precise and dependable 11-speed performance. ZERO LOSS™ engagement for fastest shifting. MatchMaker™ X compatible. Aluminum cover and forged aluminum pull lever. Discrete clamp.
SRAM X1 Chain: Designed with SRAM's trusted XX1 geometry, the X1 chain features solid pin construction, 11-speed PowerLock® and smooth, efficient shifting that you can count on every time out.
e*thirteen XCX Chain Guide: The XCX has been used by friends and employees of e*thirteen since 2004. It's been proven at the highest levels of competition, having won the Men's Elite Silver medal in the 2009 UCI World Championship Cross Country race.
Brakes:
SRAM Guide RS Brakeset: Fast isn’t about pure speed, it’s about perfect speed. It’s about knowing the right line and having the confidence to ride it. Flawlessly. The new SRAM Guide RS is precision at your fingertips, with a proven 4-piston caliper and innovative SwingLink™ lever technology that gives you more positive pad contact and increased braking authority. Light, crisp, clean and now compliments your SRAM drivetrain. Go faster.
Wheelset:
Schwalbe Nobby Nic SnakeSkin Tires (TL-Easy): Loved by touring and all-mountain riders, the Nobby Nic is seen in fast cross-country racing as well as in technically demanding Enduro competition. The SnakeSkin sidewall makes it resistant to cuts and blows, while the Tubeless conversion is easier than ever before. Nobby Nic is a mountain biker's best friend.
DT Swiss M 1700 Rims (Tubeless Ready): The M 1700 SPLINE® comes stock with tubeless rim tape and valves, just the right tool for demanding trails. The wide rim gives the tire that decisive little bit more volume while the Ratchet System® freewheel ensures safe engagements even in the most averse conditions.
DT Competition Spokes (2.0 / 1.8 / 2.0): One of the most versatile spokes in DT Swiss spoke range. DT Competition® gets its special strength from cold forging. This makes it not only extremely durable but thanks to the thinner middle section, it is 48g lighter than a spoke with a constant diameter of 1.8mm.
Additional Features:
Kindshock Lev Integra Dropper Seatpost - 125mm Travel: Internally routed cable significantly cleans up the look of your bike. Clear the clutter while benefiting from legendary LEV technology. 125mm of smooth travel executed by an air sprung hydraulically locking sealed cartridge. A forged twin bolt micro adjust head keeps the saddle on tight while KS’s patented roller-clutch bearing and replaceable brass keys ensure thousands of miles of play-free travel. A KG Alloy ODI Lock-On compatible remote connects at the post end to an all new cable interface making setup and service even easier. Increase thrills and decrease drag with Lev Integra.
