Frame/Shock:
166mm Travel UD Carbon Frame
DELTA System Suspension: The DELTA system was conceived to, among other things, achieve very complex leverage rate curves that can be used to tune for varying track conditions, spring, and damper parameters. The dual progressive leverage rate curve was developed for coil sprung downhill applications to take advantage of the speed sensitive shocks on the market. Mechanically, the system uses very compact links that can achieve a lot of angle and velocity change through the travel. Evil can tailor the leverage rate curve to really take advantage of the shock's valving and the way that a speed sensitive damper is designed to work. Ultimately the design achieves a high degree of suppleness early in the travel, with a very predictable high traction stage through the middle and a bottomless ramp at the end of the travel.
RockShox Super Deluxe Coil Ultimate Rear Shock: No-nonsense performance is the name of the game. The Super Deluxe Coil Ultimate was designed to meet all the demands of the latest and greatest hard hitting enduro and trail bikes. Featuring Maxima Plush fluid, solid threshold adjustment for pedaling performance, ride quality and compression adjustment to fine tune for any condition. The unmistakable feel of a coil spring all packed into RockShox's Super Deluxe design.
Shock Adjustments: Spring Preload, Low Speed Compression Adjustment, Threshold Switch for Pedaling Performance
Wheelie Short Chainstays: Short 430mm chainstays mean wheelies for days and manuals for months.
Pedal Forward Positioning: A steep seat tube angle puts you over the pedals, powerfully cranking uphill.
157mm Superboost Rear Spacing: Wider spacing makes for faster and stiffer handling.
Fully Internal Routing: Tubes within tubes bring setup bliss and tidy looks.
Direct Injection Chainguide: As light as it gets, this is removable for those who want to go even lighter.
Sound Mounds: Rubber sound-cancelling chainstay mounds keep you bounding in peace.
Longer. Slacker. Faster.
Threaded Bottom Bracket
Fork:
RockShox ZEB Ultimate: ZEB Ultimate is a whole new breed of fork, designed to challenge the limits and take on the world’s toughest Enduro tracks. Going Ultimate has its advantages. Featuring an all-new stiff 38mm chassis designed with the Charger 2.1 damper, DebonAir™ air spring technology, SKF Wiper Seals, and Maxima Plush Fluid. SRAM's highest performing, athlete-proven technologies matched with premium style plays. An anodized crown and ZEB’s signature color – Slab Grey – make a rocking debut.
Fork Adjustments: Charger 2.1 Damper Featuring Independent Low and High Speed Compression Adjustment, Rebound Adjustment, Air Spring Pressure
Drive Train:
Shimano XT: The original mountain bike groupset trusted by generations of mountain bikers around the world. Whatever the trail, whatever you ride, XT is your solution for mountain biking today. Reliable shifting and Intuitive maintenance are cornerstones of this solid system. XT is the high-performance workhorse you can count on.
Brakes:
Shimano XT 4-Piston: With consistent braking performance and reliable stopping power in all conditions, this four-piston brake instills confidence and control. Ice Tech rotors help keep everything cool, and those four pistons bring new levels of modulation to this trusted system.
Shimano XT Rotors: Compact and lightweight disc brake rotors feature rapid heat dissipation thanks to Ice Technologies FREEZA heat management system. Installing and removing the rotors is quick and easy with Shimano's Center Lock design.
Wheelset:
Industry Nine Enduro S Hydra: Enduro S is handbuilt for the long haul with 28 straight-pull spokes, the same proven rim profile as the EN305, and Industry Nine's finely crafted Hydra-equipped hubs. Born from an impressive bloodline, Enduro S is well situated to elevate your riding with features you won’t have to sell your first born for.
Maxxis Minion DHF Tires: With a tread design that deftly balances rolling speed with braking and cornering traction, it's hard to find fault with the Minion DHF. That's probably why it's one of the most imitated tires in mountain biking.
Additional Features:
OneUp Dropper Post: OneUp's been obsessed with shaving every last millimetre from the latest OneUp post to give you the the shortest stack height and shortest total length of any dropper post. No other post can get your saddle lower.
Evil Boomstick 7075 Aluminum Bars: At 810mm wide and with 35mm rise, these are anything but subtle.
Price and Spec Subject to Change
