Frame Update 4.0: The 4th iteration of the Furtado features variable chainstay lengths for optimal balance across the full size range. It also features a slightly slacker head angle, a slightly higher bottom bracket to account for added travel, a slightly longer reach, and a lower standover height.
Carbon CC Frame: Santa Cruz's highest grade CC-level carbon frame is every bit as stiff and strong as their C-level frame, but weighs about 280 grams less, due to the use of lighter, stronger, and more expensive carbon fiber. Santa Cruz is also able to truly integrate the shock mounts, pivot mounts, dropouts and disc brake tabs into the structure, using all uni-directional carbon plies. The shock mount isn't merely riveted or bonded on after curing, but is an integrated part of the fiber lay-up. This makes Santa Cruz's carbon frames incredibly strong and able to absorb impact better than any other frame they've tested.
Lower-Link Mounted VPP® Suspension: VPP is based on the patented principle of having two short links rotating in opposite directions. This system provides huge design flexibility, allowing Santa Cruz to manipulate shock rates to the intended purpose and character of each model; from short travel endurance bikes to World Championship winning DH machines. This redesign mounts the shock lower on the bike, making for an even better ride quality.
RockShox Super Deluxe Ultimate Rear Shock: Designed for the latest hard-hitting enduro and trail bikes, Super Deluxe Ultimate features the ride-tuning abilities of an air spring with both compression and rebound adjustment to fine tune to any trail. With a solid threshold adjustment for pedaling performance and Maxima Plush fluid for a buttery smooth feel, riders can now easily dial in a podium-worthy ride.
Shock Adjustments: + / - Low Speed Compression Adjustment from Base Tune, Open / Threshold Positions, External Rebound, Air Spring Pressure
Proportional Chainstay Lengths: With rear ends that match the size range, this bike's geo and ride quality is the same for all riders.
Bottle Cage Mount: Within the front triangle, fits piggyback shocks.
Integrated Flip Chip for High/Low Setting Adjustment
Molded Rubber Swingarm and Downtube Protection
148mm Rear Axle Spacing
Threaded Bottom Bracket
Integrated Headset
