Santa Cruz Bicycles 5010 CC XTR+ Reserve Complete Mountain Bike 2019
SKU# EB-144890-1001
$7,599.20
$9,499.00
Find in Store
Checking availability...
Not available in store
Order and get 7599 reward points
Earn 7599 points with this product. Join Free
Free shipping on orders over $50
Details
Lowest price guarantee
Details
366 Day Return Policy
DetailsSanta Cruz Bicycles 5010 CC XTR+ Reserve Complete Mountain Bike 2019
Saddling up a Santa Cruz Bicycles 5010 CC XTR+ Reserve Complete Mountain Bike is like jumping in the driver's seat of a finely tuned sports car. The 5010 has always been an agile, overly capable powerhouse and after receiving a little love in the geometry department it is now rowdier than ever. Boasting a slacker head angle, steeper seat tube and longer reach, you'll be pleasantly surprised at the sheer speed and handling this 130mm travel steed provides. Full Fox suspension, Santa Cruz's all new Reserve carbon 37 rims, 2.6" tires and Shimano's new 12-speed XTR drivetrain make the Santa Cruz Bicycles 5010 CC XTR+ Reserve Complete Mountain Bike a snappy, ultra lightweight pure trail pony that won't back down from any line.
Product Details
Frame/Shock:
Carbon CC Frame: Santa Cruz's highest grade CC-level carbon frame is every bit as stiff and strong as their C-level frame, but weighs about 280 grams less, due to the use of lighter, stronger, and more expensive carbon fiber. Santa Cruz is also able to truly integrate the shock mounts, pivot mounts, dropouts and disc brake tabs into the structure, using all uni-directional carbon plies. The shock mount isn't merely riveted or bonded on after curing, but is an integrated part of the fiber lay-up. This makes Santa Cruz's carbon frames incredibly strong and able to absorb impact better than any other frame they've tested.
130mm VPP® Suspension: VPP is based on the patented principle of having two short links rotating in opposite directions. This system provides huge design flexibility, allowing Santa Cruz to manipulate shock rates to the intended purpose and character of each model; from short travel endurance bikes to World Championship winning DH machines.
Fox DPX2 Performance Elite: Combining the best of X2 and DPS, the DPX2 features a recirculating oil damper design with the convenience of three on-the-fly compression damping positions. Performance Elite shocks retain the same adjustments, dampers, weight, and 7000 series aluminum as Factory Series, but have s black anodized finish instead of Genuine Kashima Coat. A Performance Elite graphics package is found on these forks to tie in the black-on-black look.
Shock Adjustments: Lever Actuated Open, Medium, Firm Modes | Open Mode Adjust (10 Clicks) | Rebound Adjust | Air Spring Pressure
Frame Update 3.0: The 5010 sees a longer reach, slightly slacker head angle and steeper seat angle for a more optimized ride.
27.5 / 27.5+ Wheel Clearance: Clearance for up to 2.8-inch tires.
Fork:
Fox 34 Float Factory: "Factory” says it all. The best-of-the-best technology with buttery smooth and ultra durable Genuine Kashima Coat. Designed for trail riding, the Factory Series 34 features a FIT4 damper, FLOAT EVOL air spring, and lightweight chassis. The 34 provides proven trail performance that instills confidence and control.
Fork Adjustments: FIT4 3-Position Lever Adjust (Open, Medium, Firm), Open Mode Adjust (22 Clicks), Rebound, Air Spring Pressure
Drive Train:
Shimano XTR 12-Speed M9100 Drivetrain: Optimized and built to the highest demands of racers, new XTR M9100 provides faster and smoother shifting with Shimano’s new HYPERGLIDE+ engineering and MICRO SPLINE Freehub technology. Extensive feedback from Shimano’s global mountain bike athletes delivered insights that one drivetrain does not fit all racers. With that in mind, new XTR M9100 offers a range of gearing choices, single and double front chainring setups and a unique 11-speed drivetrain option that shaves valuable weight off the system without sacrificing performance and speed. Chain retention has been drastically improved as well thanks to advancements with the new M9100 rear derailleur design.
Brakes:
Shimano XTR M9120 Brakeset: Further improving Shimano’s legendary mountain bike braking system, new XTR increases brake rigidity for greater bike control and optimizes braking performance for different riding styles. The Enduro-style 4-piston design prioritizes power and smooth braking feel.
Wheelset:
Santa Cruz Reserve 37 Carbon Wheels: Whether it's a sunset lap with friends or a race run against the clock, a broken wheel ruins any ride. SC set strength and impact resistance as their highest priority, but strength doesn't have to mean uncomfortably stiff. Their wheels are compliant enough to avoid that harsh "wooden" ride that gives some carbon rims a bad name offroad. Santa Cruz only makes offroad bikes, so they have the privilege of being able to focus purely on the mountain bike experience. Everything from the thickness of rim beads to external spoke hole reinforcements comes purely from their experience of knowing what riders need at every level—from international racing to your local trails.
Maxxis Minion DHF Front Tire: The Minion DHF was designed for the often loose and muddy conditions of aggressive all-mountain terrain. The DHF incorporates ramped knobs for low rolling resistance and channel-cut knobs to increase gripping edges, giving straight-line control and precise cornering.
Maxxis Minion DHR II Rear Tire: With side knobs borrowed from the legendary Minion DHF, but widened to provide more support, the DHR II corners like no other. The center tread features ramped leading edges to improve acceleration and sipes to create a smooth transition when leaning the bike. Paddle-like knobs on the center tread dig in under hard braking and help keep the bike under control. Pair it with a Minion DHF up front for the ultimate aggressive trail riding tire combo!
Additional Features:
RockShox Reverb Stealth Dropper Seatpost: Don’t let its familiar good looks fool you—Reverb is a whole new weapon. Its internals have been completely re-engineered to improve on its already legendary performance and to offer enhanced reliability: all the smallest details, down to the single seal, have been re-evaluated and updated to pass the hardest and longest durability tests. Additional bushing overlap also improves performance over time. This is the brand-new Reverb, engineered for the next-generation mountain biker.
Shipping Information:
Oversize Item: Ships within the continental U.S. for $69. HI and AK shipping available. Please call for details.
Specs
Fork Travel:
130mm
Rear Travel:
130mm
Handlebar:
Santa Cruz Bicycles AM Carbon
Biking Type:
Mountain
Used For:
Trail
Frame Material:
Carbon
Gearing:
1 x 12
Stanchion Diameter:
34mm
Rear Shock:
FOX DPX2 Float Factory
Shifters:
Shimano XTR M9100 SL
Rear Derailleur:
Shimano XTR M9100, 12-Speed
Crankset:
Shimano XTR M9120, 32t
Cassette:
Shimano XTR, 10-51t
Chain:
Shimano XTR M9100, 12-Speed
Pedals:
Not Included
Brake Levers:
Shimano XTR M9120
Brake Calipers:
Shimano XTR M9120
Rotors:
Shimano XTR Ice Tech Centerlock Rotors (180mm)
Headset:
Cane Creek 110 IS Integrated
Bar Tape/Grips:
Santa Cruz Palmdale Grips
Stem:
Race Face Turbine R (50mm)
Saddle:
WTB Team Silverado
Seatpost:
RockShox Reverb Stealth Dropper 31.6mm
Hubs:
DT Swiss 240 Centerlock 15x110mm Front / DT Swiss 240 HG Centerlock 12x148mm Rear
Rims:
Santa Cruz Reserve 37 Carbon
Spokes:
DT Swiss Competition
Front Tire:
Maxxis Minion DHF 2.6" | 3C MaxxTerra, EXO, TR
Rear Tire:
Maxxis Minion DHR II 2.6" | 3C MaxxTerra, EXO, TR
Warranty:
Limited Lifetime (Frame + Bearings Only)
Wheel Size:
27.5"+
